US Patent No: 9891020

Multi-platform ergonomic foregrip

---

Abstract

---

A foregrip for use with a firearm having a handguard mounting platform. The foregrip comprises a unitary body attachable to a handguard and configured with a front end, an intermediate section and a rear end. A front end designed to form a vertical engagement portion, an intermediate section designed to be partially curved engagement section and extending from the front end to the rear end, and a rear end designed to form a top portion and a lower portion. The top portion forming a first angled engagement portion, and the lower forming a second angled engagement portion. An attachment surface provides a method for mounting the foregrip onto a firearm handguard.

---



---
