The present invention relates to a doubly salient permanent magnet electric machine that has a winding structure in which series-connected windings are included in the phase windings of a mover, and that has a stator implemented as an iron core having a plurality of permanent magnets and a plurality of stator salient poles neighboring the permanent magnets, thus reducing the number of permanent magnets by half. An electric machine is configured such that a mover moves while facing a stator and includes an N (a number of power phases) multiple number of teeth and phase windings wound around the teeth, and one or more pairs of phase windings of the mover mutually having a phase difference of 180° are connected in series, and the stator includes permanent magnets in depressions between individual stator salient poles of an iron core in which the stator salient poles are formed.

Claims data not available
