Zeolite core/silica zeolite shell composite, preparing method of the same, and catalyst including the same
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Feb 13, 2018
Issued Date -
N/A
app pub date -
Feb 10, 2014
filing date -
Aug 10, 2011
priority date (Note) -
In Force
status (Latency Note)
Importance
Loading Importance Indicators...
Abstract
The present disclosure relates to a preparing method of a zeolite core/silica zeolite shell composite, which includes adding a zeolite seed crystal into a gel solution containing a silicon-source compound, a structure directing agent and a fluorine anion-source compound, and then, crystallizing the gel solution for growing a silica zeolite shell containing a crystal structure which is coherent with that of the zeolite seed crystal; a zeolite core/silica zeolite shell composite prepared by the preparing method above; and catalytic use of the zeolite core/silica zeolite shell composite.
First Claim
Other Claims data not available
Family
Loading Family data...
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 1 Citation Count
- C01B Class
- 31.00 % this patent is cited more than
- 7 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Aug 13, 2025 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Aug 13, 2029 |
