Optical module blind mating heat relay system
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Jan 23, 2018
Issued Date -
N/A
app pub date -
Dec 31, 2015
filing date -
Dec 31, 2015
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
An optical module blind mating heat relay system, comprising a linecard comprising a circuit board; a heat relay apparatus comprising a first heat pipe on the circuit board, a radiator attached to the circuit board and in thermal contact with the first heat pipe; a heat relay receiver assembly comprising a receiver housing having a slot and a contact slug connected to the receiver housing and in thermal contact with the first heat pipe; a pluggable optical module removably engaged with the linecard; and a second heat pipe having a pluggable optical module portion contacting the pluggable optical module and having a plug portion removably positioned within the slot of the receiver housing, the plug portion in thermal contact with the contact slug, the second heat pipe removable from the receiver housing while the linecard is receiving electrical power.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2015 Application Filing Year
- G02B Class
- 9095 Applications Filed
- 7457 Patents Issued To-Date
- 82 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- G02B Class
- 0 % this patent is cited more than
- 7 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Jul 23, 2025 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Jul 23, 2029 |
