Ignition system and method for operating an ignition system
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Jan 23, 2018
Issued Date -
N/A
app pub date -
Oct 16, 2014
filing date -
Nov 14, 2013
priority date (Note) -
In Force
status (Latency Note)
Importance
Loading Importance Indicators...
Abstract
A method is described for operating an ignition system for an internal combustion engine, including a primary voltage generator and a bypass, in particular, a boost converter for maintaining a spark generated with the aid of the primary voltage generator, the method includes an ascertainment of a modified energy requirement for an ignition spark, which is to be maintained with the aid of the bypass and a modification of the working mode of the bypass in response thereto.
First Claim
Other Claims data not available
Family
Loading Family data...
International Classification(s)
- 2014 Application Filing Year
- F02P Class
- 256 Applications Filed
- 210 Patents Issued To-Date
- 82.04 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 1 Citation Count
- F02P Class
- 30.28 % this patent is cited more than
- 7 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Jul 23, 2025 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Jul 23, 2029 |
