Multispectral measurement for improved biological signal acquisition
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Jan 23, 2018
Issued Date -
N/A
app pub date -
Dec 17, 2014
filing date -
Dec 17, 2014
priority date (Note) -
In Force
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
|
Patent Longevity
|
Forward Citations
|
Abstract
An embodiment includes a functional near infrared (fNIR) system comprising: first, second, and third light emitting diodes (LED) and a photo detector; and at least one storage medium having instructions stored thereon for causing the system to: (a) emit photo energy at first, second, and third wavelengths from the first, second, and third LEDs during first and second time periods, (b) determine first, second, and third optical density changes and changes in first and second chromophore concentrations based on the emitted photo energy; and (c) determine and fit first, second, and third absorption values to a first absorption spectra curve based on the determined changes in first and second chromophore concentrations. Other embodiments are described herein.
First Claim
Other Claims data not available
Family
- No Family data available.
International Classification(s)
- 2014 Application Filing Year
- A61B Class
- 14296 Applications Filed
- 12053 Patents Issued To-Date
- 84.32 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 2 Citation Count
- A61B Class
- 20.51 % this patent is cited more than
- 7 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Jul 23, 2025 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Jul 23, 2029 |
