Systems and methods for reduced latency tracking area selection
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Jan 16, 2018
Issued Date -
N/A
app pub date -
Oct 22, 2009
filing date -
Oct 22, 2009
priority date (Note) -
In Force
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
|
Patent Longevity
|
Forward Citations
|
Abstract
Some embodiments provide methods for selecting tracking areas, including: receiving a plurality of messages from a plurality of base transceiver stations, each message including a list of tracking areas handled by the base transceiver station from which the message is received; performing domain name system queries for the tracking areas to retrieve information identifying serving gateways serving the tracking areas; based on the information identifying serving gateways, storing, in a local memory, a list of tracking area identities handled by each identified serving gateway; receiving a message from user equipment indicating a first tracking area; selecting at least one tracking area handled by a serving gateway serving the first tracking area based on the list of tracking areas handled by each identified serving gateway stored in the memory; and sending a tracking area identity list to the user equipment based on the selected at least one tracking area.
First Claim
Other Claims data not available
Family
- No Family data available.
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 1 Citation Count
- H04W Class
- 0 % this patent is cited more than
- 7 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Jul 16, 2025 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Jul 16, 2029 |
