Gearbox for a vehicle and vehicle, comprising such a gearbox
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Jan 16, 2018
Issued Date -
N/A
app pub date -
May 12, 2015
filing date -
May 27, 2014
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A gearbox comprising a planetary gearbox with a ring gear, a sun wheel and a planetary wheel carrier, on which at least one planetary wheel is rotatably mounted, which ring gear and sun wheel engage with the at least one planetary wheel; and a first axially shiftable coupling sleeve, which in a first gear position disconnects an input shaft from the planetary wheel carrier, and in a second gear position disconnects the input shaft with the planetary wheel carrier. A second axially shiftable coupling sleeve arranged to connect a gearbox house with the ring gear in the first gear position, and to disconnect the gearbox house from the ring gear in the second gear position. A third axially shiftable coupling sleeve arranged to connect the ring gear with an output shaft in a third gear position, wherein the second axially shiftable coupling sleeve arranged to connect the planetary wheel carrier with the gearbox house in the third gear position.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2015 Application Filing Year
- F16H Class
- 2867 Applications Filed
- 2383 Patents Issued To-Date
- 83.12 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- F16H Class
- 0 % this patent is cited more than
- 7 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Jul 16, 2025 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Jul 16, 2029 |
