Golf club head
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Jan 16, 2018
Issued Date -
N/A
app pub date -
Aug 10, 2016
filing date -
Aug 14, 2015
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A golf club head having two adjoining flush surfaces and method of manufacturing same is disclosed. In one embodiment, a golf club head includes a main body comprising an opening and a recessed flange formed along at least a portion of a peripheral edge defining the opening; at least one compressible shim disposed on a surface of the flange, the at least one compressible shim being compressible to at least 50% of its original uncompressed thickness; and a cover plate shaped and sized to fit within the opening, wherein a first portion of a mating surface of the cover plate is affixed to the surface of the flange and a second portion of the mating surface is disposed on top of the at least one compressible shim, wherein the compressible shim is in a compressed state such that an outer surface of the cover plate is flush with an adjacent surface of the main body.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 47 Citation Count
- A63B Class
- 99.50 % this patent is cited more than
- 7 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Jul 16, 2025 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Jul 16, 2029 |
