Method and apparatus for anchoring terminal in wireless communication system
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Jan 9, 2018
Grant Date -
Sep 1, 2016
app pub date -
Oct 20, 2014
filing date -
Oct 18, 2013
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
The present disclosure relates to a pre-5th-Generation (5G) or 5G communication system to be provided for supporting higher data rates Beyond 4th-Generation (4G) communication system such as Long Term Evolution (LTE). The present invention relates to a method and apparatus for anchoring of a terminal in a wireless communication system. The method for anchoring the terminal in the wireless communication system may include receiving attribute information indicating whether at least one gateway operating as an anchor for at least one default Packet Data Network (PDN) connection supports session persistence, detecting a new flow generated by an application, determining whether a further PDN connection is required for the flow on the basis of the attribute information indicating whether at least one gateway supports session persistence, and if no further PDN connection is required for the flow, using an Internet Protocol (IP) address allocated by the at least one gateway as a source IP address of the flow.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2014 Application Filing Year
- H04L Class
- 29135 Applications Filed
- 23333 Patents Issued To-Date
- 80.09 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 1 Citation Count
- H04L Class
- 17.38 % this patent is cited more than
- 7 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Jul 9, 2025 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Jul 9, 2029 |
