Lapping assembly or process utilizing a bar stack extender
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Dec 26, 2017
Issued Date -
N/A
app pub date -
Nov 5, 2013
filing date -
Nov 5, 2013
priority date (Note) -
In Force
status (Latency Note)
Importance
Loading Importance Indicators...
Abstract
A slider bar extender to removably connect one or more slider bars to a processing machine or tool is disclosed. In illustrated embodiments, the extender is coupled to a holder structure through a tongue and groove connection. In illustrated embodiments, the tongue is formed on the holder structure and the groove is formed on the extender. In illustrated embodiments, the extender includes a plurality of reduced thickness strips. The reduced thickness strips are orientated lengthwise to control or transfer bending to one or more bars connected to a proximal edge surface of the extender.
First Claim
Other Claims data not available
Family
Loading Family data...
International Classification(s)
- 2013 Application Filing Year
- B24B Class
- 563 Applications Filed
- 515 Patents Issued To-Date
- 91.48 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- B24B Class
- 0 % this patent is cited more than
- 8 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Jun 26, 2025 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Jun 26, 2029 |
