Systems and method for AIS transponder integration with ILS/VOR receivers
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Nov 28, 2017
Grant Date -
Sep 29, 2016
app pub date -
Mar 24, 2015
filing date -
Mar 24, 2015
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A receiver includes an RF module to receive and down convert multiple types of RF signals received from at least one antenna; a communication unit configured to communicate signals with at least one external device; and a processing unit communicatively coupling the radio frequency module with the communication unit. Processing unit receives operation mode selection. When first operation mode is selected, processing unit receives first input signal from antenna via RF module (the first input signal including ILS signal and/or VOR signal) and outputs first output signal based on first input signal to external device. When second operational mode is selected, processing unit receives second input signal from antenna via radio frequency unit (second input signal including AIS signal including data regarding a current location of remotely located transmitting device) and outputs second output signal based on second input signal to external device.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 3 Citation Count
- G08G Class
- 10.84 % this patent is cited more than
- 8 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | May 28, 2025 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | May 28, 2029 |
