Microfluidic biosensing system
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Nov 28, 2017
Grant Date -
May 19, 2016
app pub date -
May 18, 2015
filing date -
Nov 19, 2014
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
Disclosed is a microfluidic biosensing system including a processor, in which a Raman barcode database corresponding to at least one Raman spectrum signal is stored, a plurality of Raman barcode beads mixed with a target fluid and coupled to at least one target bioparticle in the target fluid, a microfluidic channel disposed to make the target fluid mixed with the Raman barcode beads flow therethrough, a light source disposed on the microfluidic channel, and a spectral detection device connected to the processor and disposed to correspond to the light source. The spectral detection device receives the Raman spectrum signal generated when the target bioparticle coupled with the Raman barcode bead is irradiated, and transfers the received Raman spectrum signal to the processor. The processor determines a type of the bioparticle(s) and calculates the number of bioparticle(s) by matching the Raman spectrum signal(s) to the Raman barcode database.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2015 Application Filing Year
- G01N Class
- 11310 Applications Filed
- 8345 Patents Issued To-Date
- 73.79 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 1 Citation Count
- G01N Class
- 33.94 % this patent is cited more than
- 8 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | May 28, 2025 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | May 28, 2029 |
