Glue delivery system
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Oct 17, 2017
Issued Date -
N/A
app pub date -
Jan 26, 2016
filing date -
Jan 26, 2016
priority date (Note) -
In Force
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
|
Patent Longevity
|
Forward Citations
|
Abstract
A glue delivery system and method for providing precise application of glue on a substrate. A bead of glue is extruded from a first glue chamber through a gun to a leading edge of the substrate. A trailing edge of the substrate is blown off and over to the nozzle to receive a smear of glue from a second glue chamber. A gear pump is controlled by a servo drive that is connected to a servomotor utilizing a gear reducer. The pump regulates the extrusion of the glue onto the substrate that is programmed with empirical data of gear reducer ratio at which the glue flows within a constant speed, torque, current, speed and position of the glue. The empirical data is provided to a programmable logic circuit to achieve a precise pressure related to volume of a glue deposition and speed of the substrate onto which the glue is applied.
First Claim
Other Claims data not available
Family
- No Family data available.
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 2 Citation Count
- B29C Class
- 34.18 % this patent is cited more than
- 8 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Apr 17, 2025 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Apr 17, 2029 |
