Electrostatic discharge protection structure and fabrication method thereof
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Oct 3, 2017
Grant Date -
Jun 23, 2016
app pub date -
Feb 28, 2016
filing date -
Apr 28, 2012
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
An electrostatic discharge protection structure includes: substrate of a first type of conductivity, well region of a second type of conductivity, substrate contact region in the substrate and of the first type of conductivity, well contact region in the well region and of the second type of conductivity, substrate counter-doped region between the substrate contact region and the well contact region and of the second type of conductivity, well counter-doped region between the substrate contact region and the well contact region and of the first type of conductivity, communication region at a lateral junction between the substrate and the well region, first isolation region between the substrate counter-doped region and the communication region, second isolation region between the well counter-doped region and the communication region, oxide layer having one end on the first isolation region and another end on the substrate, and field plate structure on the oxide layer.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2016 Application Filing Year
- H01L Class
- 27971 Applications Filed
- 23507 Patents Issued To-Date
- 84.05 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- H01L Class
- 0 % this patent is cited more than
- 8 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Apr 3, 2025 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Apr 3, 2029 |
