Portable gas powered internal combustion engine arrangement
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Sep 19, 2017
Issued Date -
N/A
app pub date -
Feb 3, 2011
filing date -
Feb 6, 2007
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A gas powered internal combustion engine in which the gas is provided from the gas phase of a pressurized liquid gas in an liquified petroleum gas container and in which the liquified petroleum gas container is rigidly mounted adjacent to the internal combustion engine at a preselected angle to be in conductive heat transfer relationship to the internal combustion engine and in vibration receiving relationship to the internal combustion engine whereby the liquified gas in the liquified petroleum gas container is heated and vibrated and the effective surface area thereof is thereby increased. A pressure regulator is provided for receiving the gas from the liquified petroleum gas bottle regulating the pressure of the gas transmitted to the internal combustion engine and at least one flexible hose is connected to the pressure regulator for transmitting the gas therethrough. A vibration and/or heat limiting member may be incorporated to reduce the frequence and amplitude of the vibration and limit the amount of heat transferred to the liquified petroleum gas.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2011 Application Filing Year
- F16M Class
- 795 Applications Filed
- 345 Patents Issued To-Date
- 43.40 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 1 Citation Count
- F16M Class
- 19.07 % this patent is cited more than
- 8 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Mar 19, 2025 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Mar 19, 2029 |
