Electrode material, preparation method thereof and supercapacitor based thereof
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Aug 15, 2017
Issued Date -
N/A
app pub date -
Jan 14, 2013
filing date -
Aug 28, 2012
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
The disclosure discloses electrode material, preparation methods thereof and supercapacitors based thereof. Raw material for preparing the electrode material include PVDF and an additive which can be reacted with the PVDF to generate conductive active substance, the amount of the PVDF is 50 to 99 mass percentage, and the amount of the additive is 1 to 50 mass percentage. A PVDF-based composite film can be prepared from the raw materials; and activating treatment is performed on the film by virtue of a physico-chemical process, so that PVDF can generate a conductive active substance, the contact resistance of the PVDF and the active substance is reduced, and the conductive active substance is distributed in the PVDF-based composite film more uniformly. Button and wound supercapacitor and flexible capacitor, which are prepared from the electrode material, are high in power density and energy density, long in cycle life.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2013 Application Filing Year
- H01G Class
- 998 Applications Filed
- 904 Patents Issued To-Date
- 90.59 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 1 Citation Count
- H01G Class
- 18.57 % this patent is cited more than
- 8 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Feb 15, 2025 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Feb 15, 2029 |
