FEEDBACK SYSTEM FOR IMAGER EXPOSURE RATE CONTROL
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Jul 25, 2017
Grant Date -
Jul 27, 2017
app pub date -
Jan 27, 2016
filing date -
Jan 27, 2016
priority date (Note) -
Granted
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
Abstract
Systems and methods for extracting information from a scanned item having a plurality of regularly spaced row marks along at least part of a length of the scanned item are disclosed herein. The system can include a line scan camera that can generate a line of pixels of a portion of the scanned item in an imaging area; a feed device coupled to the line scan camera; and a timing circuit. The feed device can move at least a portion of the scanned item through the imaging area, and the timing circuit can provide a plurality of capture signals to the line scan camera. The timing circuit can vary a time interval between capture signals based on a number of pixels between adjacent row marks along at least a portion of the length of the scanned item.
First Claim
Other Claims data not available
