Air purifier device with ionizing means
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Jul 4, 2017
Issued Date -
N/A
app pub date -
Nov 20, 2014
filing date -
Feb 18, 2014
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
An air purifier device includes a chamber defined by a side wall arranged to guide an air flow through the air purifier device. The air purifier device further includes at least one emitter electrode and at least one collector plate electrode arranged to ionize airborne particles. The at least one emitter electrode is arranged to extend from the side wall and inwards in the chamber and the at least one collector plate electrode is arranged to extend from the side wall and inwards in the chamber. The air purifier device enables the side wall to be manufactured from e.g. plastic, or other non-conductive or non-magnetic material. This in turn may enable a lower weight of the air purifier device and facilitated manufacturing, as the side walls of the chamber e.g. may be formed by plastic moulding just as many other parts of the air purifier device.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2014 Application Filing Year
- B03C Class
- 198 Applications Filed
- 161 Patents Issued To-Date
- 81.32 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 17 Citation Count
- B03C Class
- 84.04 % this patent is cited more than
- 8 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 7.5 Year Payment | $3600.00 | $1800.00 | $900.00 | Jan 4, 2025 |
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Jan 4, 2029 |
