Process for manufacturing steel, for hot forming or quenching in a tool, having improved ductility
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Apr 4, 2017
Issued Date -
N/A
app pub date -
Apr 10, 2014
filing date -
Mar 14, 2007
priority date (Note) -
In Force
status (Latency Note)
Importance
Loading Importance Indicators...
Abstract
The invention relates to a steel part, the composition of the steel of which comprises, the contents being expressed by weight: 0.040%≦C≦0.100%; 0.80%≦Mn≦2.00%; Si≦0.30%; S≦0.005%; P≦0.030%; 0.010%≦Al≦0.070%; 0.015%≦Nb≦0.100%; 0.030%≦Ti≦0.080%; N≦0.009%; Cu≦0.100%; Ni≦0.100%; Cr≦0.100%; Mo≦0.100%; and Ca≦0.006%, the balance of the composition consisting of iron and inevitable impurities resulting from the smelting, the microstructure of the steel consisting of at least 75% equiaxed ferrite, martensite in an amount not less than 5% but not exceeding 20%, and bainite in an amount not exceeding 10%.
First Claim
Other Claims data not available
Family
Loading Family data...
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 2 Citation Count
- C23C Class
- 27.20 % this patent is cited more than
- 8 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Oct 4, 2028 |
