Multi-colored vehicle rear lamp
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Mar 21, 2017
Issued Date -
N/A
app pub date -
Apr 20, 2015
filing date -
Mar 12, 2013
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A lamp for the rear of a vehicle is disclosed with a light transmissive cover having a red first illuminated surface area and a clear second illuminated surface area. It has a first LED light emitter located directly beneath the red first area, a second LED light emitter located directly beneath the clear second area, and a third LED light emitter, also located directly beneath said clear second area. The third red LED light emitter is for emitting red light through the clear second area simultaneously with light transmitted through the red first area, whereby the first and second areas are adapted to collectively form a contiguous red illuminated surface area.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2015 Application Filing Year
- F21Y Class
- 711 Applications Filed
- 661 Patents Issued To-Date
- 92.97 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- F21Y Class
- 0 % this patent is cited more than
- 8 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Sep 21, 2028 |
