Silicone resin reflective substrate, manufacturing method for same, and base material composition used in reflective substrate
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Feb 21, 2017
Issued Date -
N/A
app pub date -
Dec 24, 2010
filing date -
Mar 23, 2010
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A versatile silicone resin reflective substrate which exhibits high reflectance of high luminance light from an LED light source over a wide wavelength from short wavelengths of approximately 340-500 nm, which include wavelengths from 380-400 nm near lower limit of the visible region, to longer wavelength in the infra-red region. The silicone resin reflective substrate has a reflective layer which contains a white inorganic filler powder dispersed in a three-dimensional cross linked silicone resin, the inorganic filler powder having a high reflective index than the silicone resin. The reflective layer is formed on a support body as a film, a solid, or a sheet. The silicone resin reflective substrate can be easily formed as a wiring substrate, a packaging case or the like, and can be manufactured at low cost and a high rate of production.
First Claim
Other Claims data not available
Family
International Classification(s)
- H01L:SEMICONDUCTOR DEVICES; ELECTRIC SOLID STATE DEVICE....
- C08G:MACROMOLECULAR COMPOUNDS OBTAINED OTHERWISE THAN B....
- B29C:SHAPING OR JOINING OF PLASTICS; SHAPING OF SUBSTAN....
- C09D:COATING COMPOSITIONS, e.g. PAINTS, VARNISHES, LACQ....
- B29K:INDEXING SCHEME ASSOCIATED WITH SUBCLASSES B29B, ....
- B29L:INDEXING SCHEME ASSOCIATED WITH SUBCLASS B29C, RE....
- C08L:COMPOSITIONS OF MACROMOLECULAR COMPOUNDS
Cited Art Landscape
Patent Citation Ranking
- 10 Citation Count
- H01L Class
- 18.50 % this patent is cited more than
- 8 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Aug 21, 2028 |
