Means of water surface transport
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Feb 14, 2017
Grant Date -
Jan 7, 2016
app pub date -
Feb 20, 2014
filing date -
Feb 20, 2013
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A water surface transport means, comprising a bottom (1), boards (2), a deck (3), surge diversion grooves (4) and wave suppression diversion baffles (5), the surge diversion groove (4) being provided in a space between a bottom surface vertically recessed into the hull bottom (1) and the deck (3) and extending from the bow to the stern, with an arc-shaped transverse section and a top line of longitudinal section being lower in the front and higher in the rear; a top transverse section of the wave suppression diversion baffle (5) being arc-shaped and a top line of longitudinal section being lower in the front and higher in the rear. The water surface transport means can be configured as mono-hull, catamaran and trimaran.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2014 Application Filing Year
- B63B Class
- 679 Applications Filed
- 600 Patents Issued To-Date
- 88.37 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- B63B Class
- 0 % this patent is cited more than
- 8 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Aug 14, 2028 |
