Separation of biocomponents from whole stillage
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Dec 13, 2016
Issued Date -
N/A
app pub date -
May 15, 2016
filing date -
May 15, 2016
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A multi stage process for separating oil, protein, fiber and clean water from a stream containing whole stillage byproduct from ethanol production is disclosed. In a first step, fibers are separated in a two-step process that includes a plate separator and a press. In a subsequent step, the liquid stream separated from the fibers and contains oil, protein and water is treated with a composition that causes the protein to gel. The liquid stream is then processed in a phase separator that drains the oil by gravity, removes the water by an impeller under pressure and removes the solidified protein using a scroll.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2016 Application Filing Year
- C11B Class
- 258 Applications Filed
- 169 Patents Issued To-Date
- 65.51 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 12 Citation Count
- C11B Class
- 91.89 % this patent is cited more than
- 9 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Jun 13, 2028 |
