Vehicle mirror apparatus
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
May 17, 2016
Grant Date -
Aug 21, 2014
app pub date -
Feb 19, 2014
filing date -
Feb 20, 2013
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
Moving a mover for mirror surface angle detection following a nut member along a male thread member in such a manner that the mover is rotatable relative to the nut member and is non-rotatable relative to the male thread member, without biasing the mover by means of a spring. A communication hole is provided in a male thread member along a shaft axis of the male thread member. A mover is inserted through the communication hole so as to be movable in an axial direction. A front end of the mover is connected to a position in a back of a front end of a nut member so as to be rotatable relative to the nut member around the axis of the nut member. A position detection device detects a position of the mover relative to a base member in a direction along the male thread member.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- G02B Class
- 0 % this patent is cited more than
- 9 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Nov 17, 2027 |
