Illuminant device and lighting module thereof
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Apr 5, 2016
Grant Date -
Jun 25, 2015
app pub date -
Dec 20, 2013
filing date -
Dec 20, 2013
priority date (Note) -
In Force
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
|
Patent Longevity
|
Forward Citations
|
Abstract
A lighting module includes a main circuit board, a plurality of lighting units, and a driving unit. The main circuit board forms a plurality of through holes. Each lighting unit includes a transparent substrate, a circuit layer, a plurality of light emitting diode (LED) dies, and a transparent resin layer. The transparent substrates are arranged on the main circuit board, and then a predetermined angle spans between a first surface of each transparent substrate and the main circuit board. The circuit layer and the LED dies are placed on the first surface, and the LED dies are electrically connected to the circuit layer. The transparent resin layer covers the LED dies. The driving unit includes a driving circuit board including a plurality of protrusions. The protrusions are respectively inserted into the through holes such that the driving circuit board is substantially perpendicular to the main board.
First Claim
Other Claims data not available
Family
- No Family data available.
International Classification(s)
- 2013 Application Filing Year
- F21V Class
- 3052 Applications Filed
- 2652 Patents Issued To-Date
- 86.90 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- F21V Class
- 0 % this patent is cited more than
- 9 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Oct 5, 2027 |
