Integrated plastic restraint
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Nov 24, 2015
Grant Date -
Apr 23, 2015
app pub date -
Oct 21, 2013
filing date -
Oct 21, 2013
priority date (Note) -
In Force
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
|
Patent Longevity
|
Forward Citations
|
Abstract
An apparatus includes an elongated peg and box tube, the peg and box tube are coaxially aligned along a longitudinal axis of the respective peg and are concentric, first and second apertures extending through the peg and box tube, first and second respective arms within the peg each with a plurality of teeth from an exterior wall towards a second, opposing side of the peg directly adjacent one of the first and second apertures and a strap extending from each of the peg and box tube and from opposing longitudinal ends, wherein each of the straps has a plurality of notches extending perpendicular to a longitudinal axis of the strap, where each of the plurality of teeth of the respective arms engages one of the plurality of notches of a respective strap inserted through a corresponding one of the first and second apertures.
First Claim
Other Claims data not available
Family
- No Family data available.
International Classification(s)
- 2013 Application Filing Year
- E05B Class
- 711 Applications Filed
- 633 Patents Issued To-Date
- 89.03 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 4 Citation Count
- E05B Class
- 10.62 % this patent is cited more than
- 10 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | May 24, 2027 |
