Apparatus for imparting phase shift to input waveform
Number of patents in Portfolio can not be more than 2000
United States of America
Stats
-
Nov 10, 2015
Issued Date -
N/A
app pub date -
Oct 14, 2009
filing date -
Oct 14, 2009
priority date (Note) -
Withdrawn
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
|
Patent Longevity
|
Forward Citations
|
Abstract
There is set forth in one embodiment an apparatus and method for imparting a phase shift to an input waveform for output of a converted waveform. In one embodiment, a phase shift can be provided by four wave mixing of an input waveform and a pump pulse. In one embodiment, there is set forth an apparatus and method for generating a high resolution time domain representation of an input waveform comprising: dispersing the input waveform to generate a dispersed input waveform; subjecting the dispersed input waveform to four wave mixing by combining the dispersed input waveform with a dispersed pump pulse to generate a converted waveform; and presenting the converted waveform to a detector unit. In one embodiment a detector unit can include a spectrometer (spectrum analyzer) for recording of the converted waveform and output of a record representing the input waveform.
First Claim
Other Claims data not available
Family
| Country | kind | publication No. | Filing Date | Type | Sub-Type |
|---|
International Classification(s)
- 2009 Application Filing Year
- G01J Class
- 1212 Applications Filed
- 686 Patents Issued To-Date
- 56.61 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- G01J Class
- 0 % this patent is cited more than
- 10 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | May 10, 2027 |
