High voltage high current transmission line
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Nov 3, 2015
Grant Date -
Sep 18, 2014
app pub date -
Mar 15, 2013
filing date -
Mar 15, 2013
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A high voltage high current transmission line for transmitting high voltage high current energy in the 10 kV and 200,000 A range from a power source to an end item to which the power is delivered. The high voltage high current transmission line includes two generally parallel configured conductive plates with an overlapping dielectric layering configuration. Each of the conductive plates are encompassed by a first dielectric material, both of the conductive plates encompassed by a second dielectric material, and the conductive plates are encompassed by an outer dielectric sheathing. The dielectric layering configuration may also include a dielectric material applied to the edges of the conductive plates. At one or both ends of the high voltage high current transmission line, a plug assembly may be provided for connecting to the power source and/or the discharge device. The high voltage high current transmission line may also include an exposed conductive plate surface with a staggered configuration such that the exposed surfaces of the conductive plates do not overlap.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2013 Application Filing Year
- H01R Class
- 2765 Applications Filed
- 2646 Patents Issued To-Date
- 95.70 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- H01R Class
- 0 % this patent is cited more than
- 10 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | May 3, 2027 |
