Transportation of refinery solids waste
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Jul 14, 2015
Issued Date -
N/A
app pub date -
Apr 18, 2014
filing date -
Jan 15, 2013
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
An apparatus for mixing tank contents including sedimentary material is disclosed. The apparatus includes an agitator connected to a support including a plurality of detachable sections. The apparatus further includes a frame adjacent an opening in a top of the tank. The apparatus also includes an actuatable connector for interconnecting the frame to the support. The connector is configured to be actuated in order to lift a first portion of the support above the frame while a second portion of the support below the frame is maintained, to thereby cause a gap between the first portion and the second portion enabling at least one of the detachable sections to be inserted into the gap. The apparatus also includes at least one actuator for causing the connector to lift the first portion in order to cause the gap, and for lowering the first portion and the second portion.
First Claim
Other Claims data not available
Family
International Classification(s)
- F23G:CREMATION FURNACES; CONSUMING WASTE BY COMBUSTION
- B08B:CLEANING IN GENERAL; PREVENTION OF FOULING IN GENE....
- B65G:TRANSPORT OR STORAGE DEVICES, e.g. CONVEYERS FOR L....
- B09B:DISPOSAL OF SOLID WASTE
- B60P:VEHICLES ADAPTED FOR LOAD TRANSPORTATION OR TO TRA....
- B01F:MIXING, e.g. DISSOLVING, EMULSIFYING, DISPERSING
- 2014 Application Filing Year
- F23G Class
- 116 Applications Filed
- 95 Patents Issued To-Date
- 81.90 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 4 Citation Count
- F23G Class
- 27.27 % this patent is cited more than
- 10 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Jan 14, 2027 |
