Deburring machine and method for deburring
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Apr 28, 2015
Grant Date -
Jul 10, 2014
app pub date -
Jan 4, 2013
filing date -
Jan 4, 2013
priority date (Note) -
In Force
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
|
Patent Longevity
|
Forward Citations
|
Abstract
A method for deburring a ground metal part includes loading a ground metal part into a carrier, contacting a first planar surface of the ground metal part with a first grinding wheel, and contacting a second planar surface of the ground metal part with a second grinding wheel. The first grinding wheel is rotated in a first rotational direction. The second grinding wheel is rotated also in the first rotational direction. After the first grinding wheel is rotated in the first rotational direction, the first grinding wheel is then rotated in a second rotational direction, which is opposite to the first rotational direction. After the second grinding wheel is rotated in the first rotational direction, the second grinding wheel is also rotated in the second rotational direction.
First Claim
Other Claims data not available
Family
- No Family data available.
International Classification(s)
- 2013 Application Filing Year
- B24B Class
- 563 Applications Filed
- 515 Patents Issued To-Date
- 91.48 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 0 Citation Count
- B24B Class
- 0 % this patent is cited more than
- 10 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Oct 28, 2026 |
