Contact-making and connection arrangement on the basis of film conductors introduced in a housing
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Oct 7, 2014
Grant Date -
Feb 14, 2013
app pub date -
Apr 29, 2011
filing date -
Apr 30, 2010
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
The invention relates to a contact-making and connection arrangement on the basis of film conductors introduced in a housing, wherein ends of the film conductors have a contact-making section and at least partly lie one above another. According to the invention, a double-sided self-adhesive or adhesive-coated conductive nonwoven material is situated between the contact-making sections facing one another, said material mechanically and electrically connecting the ends of the film conductors. Furthermore, the housing is embodied such that it is divided in the plane of the film conductors that have been introduced or are to be introduced, wherein the housing parts form half-shells and, in at least one half-shell, stamp-like projections are provided which lead to a deformation of the contact-making layer in such a way that a reduction of the electrical contact resistance of the connection occurs.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 4 Citation Count
- H01R Class
- 7.51 % this patent is cited more than
- 11 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Apr 7, 2026 |
