Apparatus for vaporizing and reforming liquid fuels
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Aug 5, 2014
Grant Date -
Dec 8, 2011
app pub date -
Jun 3, 2011
filing date -
Jul 31, 2003
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
The present invention is an apparatus for the gasification of liquid fuels, involving: (a) a nozzle for atomizing and feeding a liquid fuel into a mixing region; (b) an inlet for feeding an oxidizer into the mixing region; (c) the mixing region for mixing the atomized fuel with the oxidizer; (d) a radiation hot box for vaporizing the liquid fuel, the radiation hot box comprising an ignition source positioned inside coiled catalytic reactor; (e) the coiled catalytic reactor comprising a coiled metal screen providing for a radial flow path from an inner diameter to an outer diameter of the coiled metal screen and providing for a plurality of void volumes in random order along the flow path from the inner diameter to the outer diameter; and (f) an outlet for exiting a gaseous reformate.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 11 Citation Count
- B01J Class
- 73.54 % this patent is cited more than
- 11 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Feb 5, 2026 |
