Dock system including collapsible frame, and method for assembling dock system including collapsible frame
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Jun 3, 2014
Grant Date -
Aug 16, 2012
app pub date -
Feb 15, 2012
filing date -
Feb 15, 2011
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A dock system including a collapsible frame, and method for assembling the dock system including collapsible frame are provided. A collapsible dock system includes a collapsible frame. The collapsible frame includes a first beam, a second beam, a cross-member, and a hinged bracket system. The cross-member system secures the first beam to the second beam. The hinged bracket system is selectively coupled to the first beam and the second beam in either a compact transport state in which the first beam is movable relative to the second beam or a fixed installation state in which the first beam is fixed relative to the second beam.
First Claim
Other Claims data not available
Family
International Classification(s)
- 2012 Application Filing Year
- B63B Class
- 451 Applications Filed
- 393 Patents Issued To-Date
- 87.14 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 3 Citation Count
- B63B Class
- 9.49 % this patent is cited more than
- 11 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Dec 3, 2025 |
