Automotive insulating trim part
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Jan 28, 2014
Grant Date -
Mar 7, 2013
app pub date -
Aug 2, 2012
filing date -
Mar 9, 2010
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A sound insulating trim part with acoustic mass-spring characteristics is provided. The sound insulating trim part includes a mass layer and a decoupling layer. The mass layer includes a porous fibrous layer with a dynamic Young's modulus E of at least about 96·AW·t (Pa), with AW being an area weight (g/m2), and t being a thickness (mm) of the porous fibrous layer. The mass layer also includes an air impervious thin barrier layer. The barrier layer is disposed between the porous fibrous layer and the decoupling layer. The barrier layer, the porous fibrous layer, and the decoupling layers are laminated together.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 5 Citation Count
- E04B Class
- 10.75 % this patent is cited more than
- 11 Age
Maintenance Fees
| Fee | Large entity fee | small entity fee | micro entity fee | due date |
|---|---|---|---|---|
| 11.5 Year Payment | $7400.00 | $3700.00 | $1850.00 | Jul 28, 2025 |
