Articulated combine with unloading and rear bogey steering architecture
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Oct 23, 2012
Grant Date -
Jun 3, 2010
app pub date -
Feb 5, 2010
filing date -
Dec 18, 2007
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
An articulated harvester is composed of a forward bogey having an operator's cab, an engine, a grain harvesting assembly, a grain transfer assembly, but being devoid of an on-board grain bin. A rearward bogey is attached by a joint to the forward bogey and has a powered wheel assembly, an on-board grain bin for receiving grain from the forward bogey grain transfer assembly, and a grain off-loading assembly. The forward bogey wheel assembly is powered by a first drive system. The rearward bogey wheel assembly is powered by a second drive system. Each of the first and second powered drive systems includes coordinated transmission and drive motors.
First Claim
Other Claims data not available
