Valve metal particles uniformly containing nitrogen and the method for preparing the same, the valve metal green pellets and sintered pellets, and the electrolytic capacitor anodes
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Aug 7, 2012
Grant Date -
Jul 16, 2009
app pub date -
Oct 14, 2008
filing date -
Jan 11, 2008
priority date (Note) -
In Force
status (Latency Note)
![]() |
A preliminary load of PAIR data current through [] has been loaded. Any more recent PAIR data will be loaded within twenty-four hours. |
PAIR data current through []
A preliminary load of cached data will be loaded soon.
Any more recent PAIR data will be loaded within twenty-four hours.
![]() |
Next PAIR Update Scheduled on [ ] |

Importance

US Family Size
|
Non-US Coverage
|
Patent Longevity
|
Forward Citations
|
Abstract
The present invention relates to valve metal particles uniformly containing nitrogen and a method for preparing the same, and a valve metal green pellet and a sintered pellet made from the particles, and an electrolytic capacitor anode. The present invention provides valve metal particles uniformly containing nitrogen, wherein the difference ratio of nitrogen contents of particles is 20% or less. The present invention provides a process for preparing said valve metal particles uniformly containing nitrogen, wherein the raw material particles of the valve metal were heated in a nitrogen-containing gas at a temperature of 200° C. or less for 2 hours or more. The present invention also provides a valve metal green pellet made from said valve metal particles. The present invention also provides a valve metal sintered pellet.
First Claim
all claims..Other Claims data not available
Family

- 15 United States
- 10 France
- 8 Japan
- 7 China
- 5 Korea
- 2 Other
Patent Owner(s)
Patent Owner | Address | |
---|---|---|
NINGXIA ORIENT TANTALUM INDUSTRY CO LTD | SHIZUISHAN NINGXIA 753000 |
International Classification(s)

- 2008 Application Filing Year
- C23C Class
- 1299 Applications Filed
- 709 Patents Issued To-Date
- 54.59 % Issued To-Date
Inventor(s)
Inventor Name | Address | # of filed Patents | Total Citations |
---|---|---|---|
Cheng, Yuewei | Shizuishan, CN | 11 | 41 |
# of filed Patents : 11 Total Citations : 41 | |||
Dong, Xuecheng | Shizuishan, CN | 7 | 5 |
# of filed Patents : 7 Total Citations : 5 | |||
Li, Bin | Shizuishan, CN | 1200 | 10531 |
# of filed Patents : 1200 Total Citations : 10531 | |||
Ma, Yuezhong | Shizuishan, CN | 6 | 42 |
# of filed Patents : 6 Total Citations : 42 | |||
Pan, Luntao | Shizuishan, CN | 3 | 55 |
# of filed Patents : 3 Total Citations : 55 | |||
Wang, Zhidao | Shizuishan, CN | 5 | 4 |
# of filed Patents : 5 Total Citations : 4 | |||
Zhang, Xueqing | Shizuishan, CN | 30 | 195 |
# of filed Patents : 30 Total Citations : 195 | |||
Zheng, Aiguo | Shizuishan, CN | 11 | 34 |
# of filed Patents : 11 Total Citations : 34 | |||
Zhu, Baojun | Shizuishan, CN | 1 | 2 |
# of filed Patents : 1 Total Citations : 2 |
Cited Art Landscape
- No Cited Art to Display

Patent Citation Ranking
- 0 Citation Count
- C23C Class
- 0 % this patent is cited more than
- 13 Age
Forward Cite Landscape
- No Forward Cites to Display

Maintenance Fees
Fee | Large entity fee | small entity fee | micro entity fee | due date |
---|
Fee | Large entity fee | small entity fee | micro entity fee |
---|---|---|---|
Surcharge after expiration - Late payment is unavoidable | $700.00 | $350.00 | $175.00 |
Surcharge after expiration - Late payment is unintentional | $1,640.00 | $820.00 | $410.00 |
Full Text

Legal Events
Date | Code | Event | Description |
---|---|---|---|
Jan 31, 2018 | STCH | INFORMATION ON STATUS: PATENT DISCONTINUATION | free format text: PATENT EXPIRED DUE TO NONPAYMENT OF MAINTENANCE FEES UNDER 37 CFR 1.362 |
Sep 18, 1996 | FP | LAPSED DUE TO FAILURE TO PAY MAINTENANCE FEE | Effective Date: Sep 18, 1996 |
Sep 15, 1996 | LAPS | LAPSE FOR FAILURE TO PAY MAINTENANCE FEES | |
Apr 23, 1996 | REMI | MAINTENANCE FEE REMINDER MAILED | |
Sep 27, 1991 | FPAY | FEE PAYMENT | year of fee payment: 4 |
Nov 01, 1990 | FEPP | FEE PAYMENT PROCEDURE | free format text: PAYOR NUMBER ASSIGNED (ORIGINAL EVENT CODE: ASPN); ENTITY STATUS OF PATENT OWNER: LARGE ENTITY |
Sep 13, 1988 | I | Issuance | |
Apr 09, 1985 | F | Filing | |
Apr 02, 1985 | AS | ASSIGNMENT | free format text: ASSIGNMENT OF ASSIGNORS INTEREST.;ASSIGNOR:SCHAUPERT, KURT;REEL/FRAME:004393/0760 Owner name: GESELLSCHAFT FUR SCHWERIONENFORSCHUNG MBH, DARMSTA Effective Date: Apr 02, 1985 |
Dec 12, 1984 | PD | Priority Date |
