Armrest with cup holder
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Jul 31, 2012
Grant Date -
Sep 30, 2010
app pub date -
Mar 26, 2009
filing date -
Mar 26, 2009
priority date (Note) -
Expired
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
Patent Longevity
|
Forward Citations
|
Abstract
An armrest with cup holder is disclosed, in which the cup holder is secured in the upper surface thereof, and that upper surface is covered with an upper cover section of trim cover assembly. Localized portions of the afore-said upper cover section, which lie between a flange of the cup holder and a lateral wall of the armrest, are each formed with an extension in the free end thereof. That extension is folded together with the corresponding end of the upper cover section and retained between the flange of cup holder and a support member provided around the flange of cup holder, thereby making protrudent the localized portions to compensate for and eliminate an objectionable recessed areas between those localized portions and cup holder flange.
