Method of making a coated cemented carbide insert
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
May 29, 2012
Grant Date -
Sep 1, 2011
app pub date -
May 11, 2011
filing date -
Jul 13, 2007
priority date (Note) -
Expired
status (Latency Note)
Importance
Loading Importance Indicators...
Abstract
Forming coated cemented carbide inserts, particularly useful in fine turning of super alloys. The inserts are characterized by a composition of a cemented carbide of WC, about 4.0 wt-% Co to about 7.0 wt-% Co, about 0.25 wt-% Cr to 0.50 wt-% Cr, and a coercivity (Hc) of about 28 kA/m to about 38 kA/m. The coating comprises a single (Ti1-xSix)N-layer, where x is between about 0.1 and about 0.25, with a crystal structure of NaCl type and a total thickness between about 0.5 μm and about 2.0 μm with a strong (200)-texture.
First Claim
Other Claims data not available
