Fluid rotation system for a cavitation chamber
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Mar 16, 2010
Grant Date -
Jul 20, 2006
app pub date -
Jan 18, 2005
filing date -
Jan 18, 2005
priority date (Note) -
Expired
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
Patent Longevity
|
Forward Citations
|
Abstract
A system for achieving bubble stability within a cavitation chamber is provided. The system includes an impeller assembly, the impeller assembly having at least one impeller located within the cavitation chamber. A motor, coupled to the impeller by a drive shaft, rotates the impeller thereby causing bubbles within the cavitation chamber to move toward the impeller's axis of rotation. As a consequence, the bubbles become more stable. Preferably the axis of rotation of the impeller is positioned in a substantially horizontal plane, thus allowing the rotating impeller to counteract the tendency of the bubbles to drift upward and to accumulate on the upper, inner surfaces of the cavitation chamber. The impeller can be rotated continuously throughout the cavitation process or stopped prior to cavitating the bubbles within the cavitation chamber. In the latter scenario, the impeller can be stopped, and if desired locked, at a specific rotational position, thus minimizing possible interference between the impeller and the source of the cavitation energy. The impeller can be shaped to correspond to the inner surface of the cavitation chamber, for example spherically or cylindrically, and can utilize multiple impeller blades.
First Claim
Other Claims data not available
