Error detection/correction method
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Dec 15, 2009
Grant Date -
Dec 23, 2004
app pub date -
Mar 11, 2004
filing date -
Nov 5, 1991
priority date (Note) -
Expired
status (Latency Note)
Importance
|
US Family Size
|
Non-US Coverage
|
Patent Longevity
|
Forward Citations
|
Abstract
A method for error detection and correction (EDC) includes: generating a complete EDC code in response to a data packet; distributing the complete EDC code among the data packet to create a plurality of bytes, each including a data portion from the data packet and an EDC code portion from the complete EDC code; storing the bytes in a memory module; retrieving the bytes from the memory module; forwarding the data portions of the bytes retrieved from the memory module to a requesting device; providing the data portions of the bytes retrieved from the memory module to an EDC functional block; providing the EDC code portions of the bytes retrieved from the memory module to the EDC functional block; and performing error checking and correction in the EDC functional block upon receiving the complete EDC code from the provided EDC code portions.
First Claim
Other Claims data not available
Family
| Country | kind | publication No. | Filing Date | Type | Sub-Type |
|---|
International Classification(s)
- 2004 Application Filing Year
- H03M Class
- 1501 Applications Filed
- 833 Patents Issued To-Date
- 55.50 % Issued To-Date
Cited Art Landscape
Patent Citation Ranking
- 9 Citation Count
- H03M Class
- 2.77 % this patent is cited more than
- 16 Age
