Battery connecting structure
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Mar 4, 2008
Grant Date -
N/A
app pub date -
Dec 29, 2006
filing date -
Dec 29, 2006
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
The present invention provides an improved battery connecting structure, structured from a frontal disposed portion, an abutting joint portion and a joining portion. A movement device is configured interior of the frontal disposed portion, and conducting wires extend therefrom and connect to connecting holes corresponding to conductive contact tags of the joining portion, and turning shafts are located on the frontal disposed portion corresponding to the conductive contact tags of the connecting holes. Conducting wires further extend from connecting holes of the joining portion and connect to a power supply member. Accordingly, when a rotating movement is performed on the frontal disposed portion and the joining portion by means of the turning shafts, then the conductive contact tags of the abutting joint portion serve to realize an electric circuit, thererby achieving objectives of preventing exposing and damaging the conducting wires, and providing convenience of use and portability.
