Film deposition method
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
May 29, 2007
Issued Date -
N/A
app pub date -
Jun 1, 2004
filing date -
Sep 20, 2001
priority date (Note) -
Expired
status (Latency Note)
Importance
Abstract
A film deposition method and film deposition system for depositing a halogen compound film, capable of depositing such a film while suppressing abuse that occurs due to deficiency of a halogen element even if the halogen element is dissociated from a film material. The halogen compound film is deposited through a process including: evaporating a film material comprising a halogen compound by means of an evaporation source 3; ionizing the evaporated film material with a radio frequency power outputted from a radio frequency power supply unit 11 and supplied through a substrate holder 2; and causing the ionized film material deposit on the substrate 5. A bias voltage outputted from a bias power supply unit 12 and applied to the substrate holder 2 causes halogen ions dissociated from ions of the halogen compound to be incorporated into the film being deposited on the substrate 5.
