Lighting device and lighting method
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
May 8, 2007
Grant Date -
N/A
app pub date -
Dec 4, 2006
filing date -
Dec 21, 2005
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A lighting device comprising first and second groups of solid state light emitters, which emit light having dominant wavelength in ranges of from 430 nm to 480 nm and from 600 nm to 630 nm, respectively, and a first group of lumiphors which emit light having dominant wavelength in the range of from 555 nm to 585 nm. If current is supplied to a power line, a combination of (1) light exiting the lighting device which was emitted by the first group of emitters, and (2) light exiting the lighting device which was emitted by the first group of lumiphors would, in an absence of any additional light, produce a sub-mixture of light having x, y color coordinates within an area on a 1931 CIE Chromaticity Diagram defined by points having coordinates (0.32, 0.40), (0.36, 0.48), (0.43, 0.45), (0.42, 0.42), (0.36, 0.38). Also provided is a method of lighting.
First Claim
Other Claims data not available
