Toroidal continuously variable transmission control apparatus

Number of patents in Portfolio can not be more than 2000

United States of America Patent

PATENT NO 6931316
APP PUB NO 20030228952A1
SERIAL NO

10436162

Stats

ATTORNEY / AGENT: (SPONSORED)

Importance

Loading Importance Indicators... loading....

Abstract

See full text

In a toroidal continuously variable transmission (TCVT) control apparatus with a variator unit and a ratio control hydraulic system, an electronic TCVT control unit electronically feedback-controls a transmission ratio based on a deviation from a desired transmission ratio, and generates a normal-period command signal to be input to a step motor for compensating for the deviation. The control unit determines whether the deviation can be compensated for by electronically feedback-controlling the transmission ratio based on the deviation and generates an abnormal-period command signal to be input to the step motor to realize a step-motor displacement capable of shifting or diverging the transmission ratio to a speed-reduction side, while keeping a trunnion out of contact with a stopper in the direction of the trunnion axis, when the deviation cannot be compensated for by electronically feedback-controlling the transmission ratio based on the deviation.

First Claim

See full text

Other Claims data not available

Family

Loading Family data... loading....

Patent Owner(s)

Patent OwnerAddress
NISSAN MOTOR CO LTDYOKOHAMA-SHI KANAGAWA

International Classification(s)

Inventor(s)

Inventor Name Address # of filed Patents Total Citations
Joe, Shinichiro Kanagawa, JP 26 1292
Kawabe, Taketoshi Yokohama, JP 34 2009

Cited Art Landscape

Load Citation

Patent Citation Ranking

  • 182 Citation Count
  • G06F Class
  • 93.55 % this patent is cited more than
  • 20 Age
Citation count rangeNumber of patents cited in rangeNumber of patents cited in various citation count ranges297635573292601661048662504516901 - 1011 - 2021 - 3031 - 4041 - 5051 - 6061 - 7071 - 8081 - 9091 - 100100 +050100150200250300350400450500550600650700750800850
