Shade tarp as sun shield
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Apr 5, 2005
Grant Date -
Mar 4, 2004
app pub date -
Aug 11, 2003
filing date -
Aug 29, 2002
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A sun shield which can be moved between an operating position under a translucent or transparent roof area of a motor vehicle roof (4) and a rest area next to this roof area, with a shade tarp (10) which is located underneath the roof (4) and which can be wound onto a take-up roller (12). A free end (22) of the shade tarp (10) is fixed in a transverse bow (18, 118) with pre-tensioning in the transverse direction in the transverse bow (18). Fixing of the free end (22) of the shade tarp (10) in the transverse bow (18, 118) is preferably via insertion of a turn-down portion of the free end of the tarp (10) into a groove of the transverse bow (18, 118) where it is held by pins or clamping elements formed by plastic deformation of areas of the transverse bow (18, 118).
First Claim
Other Claims data not available
Family
