Light energized tissue adhesive conformal patch

Number of patents in Portfolio can not be more than 2000

United States of America Patent

PATENT NO 6773699
SERIAL NO

09973385

Stats

ATTORNEY / AGENT: (SPONSORED)

Importance

Calculated Rating
US Family Size
Non-US Coverage
Patent Longevity
Forward Citations

Abstract

See full text

Consistent with the present invention, tissue adhesive compositions and an associated laser exposure system are provided for bonding or sealing biological tissues. The compositions are comprised of chemically derivatized soluble collagen which is formulated to concentrations ranging from 300 mg/ml (30%) to 80 mg/ml (80%) collagen protein. In particular, Type I collagen, for example, is first prepared by extraction from bovine or porcine hide and purified. The collagen preparations are then chemically derivatized with sulfhydryl reagents to improve cohesive strength and with secondary derivatizing agents, such as carboxyl groups, to improve the adhesive strength of the solder to the tissue. The compositions are then formed into viscous solutions, gels or solid films which are used to encapsulate structural components such as a cojoinal network or mesh. The resultant patch which when exposed to energy generated from an infrared laser, for example, undergo thermally induced phase transitions. Solid or semi-solid protein compositions become less viscous enabling the high concentration protein to penetrate the interstices of treated biological tissue or to fill voids in tissue. As thermal energy is released into the surrounding environment, the protein compositions again become solid or semi-solid, adhering to the treated tissue or tissue space and are reinforced by the embedded cojoinal network or mesh.

First Claim

See full text

Other Claims data not available

Family

PCTEP
+
−
  • No Family data available.

Patent Owner(s)

Patent OwnerAddress
CONVERSION ENERGY ENTERPRISES INC81 PINEBROOK ROAD SPRING VALLEY NY 10977

International Classification(s)

loading....
  • 2001 Application Filing Year
  • A61K Class
  • 10449 Applications Filed
  • 3517 Patents Issued To-Date
  • 33.66 % Issued To-Date
Click to zoom InYear of Issuance% of Matters IssuedCumulative IssuancesYearly Issuances2001200220032004200520062007200820092010201120122013201420152016201720180255075100

Inventor(s)

Inventor Name Address # of filed Patents Total Citations
DeVore, Braden P Westerly, RI 4 173
DeVore, Dale P Chelmsford, MA 49 2299
Soltz, Barbara A Spring Valley, NY 11 369
Soltz, Michael A Pleasanton, CA 30 19251
Soltz, Robert Spring Valley, NY 13 402

Cited Art Landscape

Load Citation

Patent Citation Ranking

  • 71 Citation Count
  • A61K Class
  • 97.39 % this patent is cited more than
  • 21 Age
Citation count rangeNumber of patents cited in rangeNumber of patents cited in various citation count ranges3131864645305140795337337133901 - 1011 - 2021 - 3031 - 4041 - 5051 - 6061 - 7071 - 8081 - 9091 - 100100 +010020030040050060070080090010001100120013001400150016001700180019002000
