Remote control with LED capabilities
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Dec 17, 2002
Issued Date -
N/A
app pub date -
Jun 1, 2001
filing date -
Oct 14, 1987
priority date (Note) -
Expired
status (Latency Note)
Importance
Abstract
A universal remote control comprising a keyboard having a plurality of pushbuttons including a macro pushbutton and a library of codes and data for use in transmitting operating commands to a plurality of different home appliances of different manufacturers. Instructions within the remote control are used to match the universal remote control to a plurality of different home appliances of different manufacturers such that selected codes and data from the library are used to transmit operating commands to the matched home appliances in response to activation of selected pushbuttons of the keyboard. The instructions are also used to assign to the macro pushbutton a subset of the selected codes and data from the library whereafter activation of the macro pushbutton causes the universal remote control to use the subset of selected codes and data from the library to transmit operating commands to one or more of the matched home appliances.
First Claim
Other Claims data not available
