Method and apparatus for receiving and displaying digital data
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Feb 9, 1999
Grant Date -
N/A
app pub date -
Feb 26, 1997
filing date -
Feb 26, 1997
priority date (Note) -
Expired
status (Latency Note)
Importance
Abstract
A method and an apparatus are provided for displaying a value of a measured parameter for an engine-driven vehicle, such as the speed of an engine. The apparatus includes a microcontroller which receives a data signal from a data concentrator. The data signal contains information relating to the value of a parameter which has been measured by a sensor or other measuring device. Based on the value of the data signal the microcontroller generates one or more motor control signals. The motor control signals are used to drive a stepper-motor. The motor rotates an output shaft which has a pointer mounted near one end of the shaft. The angular position of the output shaft upon rotation corresponds to the value of the parameter and the pointer helps to provide a human-readable format for the parameter value.
First Claim
Other Claims data not available
Family
International Classification(s)
Cited Art Landscape
Patent Citation Ranking
- 9 Citation Count
- H02P Class
- 1.61 % this patent is cited more than
- 26 Age
