Bicycle rear suspension system
Number of patents in Portfolio can not be more than 2000
United States of America Patent
Stats
-
Sep 10, 1996
Grant Date -
N/A
app pub date -
Jan 25, 1995
filing date -
Jan 25, 1995
priority date (Note) -
In Force
status (Latency Note)
Importance
Abstract
A rear suspension system for a bicycle. The system directs the rear wheel along a predetermined, S-shaped path as the suspension is compressed. The path is configured to provide a chainstay lengthening effect only at those points where this is needed to counterbalance the pedal inputs of the rider; at those points in the wheel travel path where there is a chainstay lengthening effect, the chain tension which results from the pedal inputs exerts a downward force on the rear wheel, preventing unwanted compression of the suspension. The system employs a dual eccentric crank mechanism mounted adjacent the bottom bracket shell to provide the desired control characteristics.
First Claim
Other Claims data not available
